Battery Specification
| Model | 123464 | Capacity | 2800 mAh |
|---|---|---|---|
| Nominal Voltage | 3.7 V | Maximum Charge Voltage | 4.2 V |
| Internal Resistance | <150 mΩ | Typical Cell Weight | 45.0 g |
| Cell Dimensions (T×W×L) | 12*34*64 mm (T × W × L) | ||
| Finished Pack Dimensions (with PCM & Wires) | 12*34*66 mm (T × W × L) Note: Final dimensions may vary depending on PCM placement, wire routing, connector type, or custom installation requirements. | ||
| Connector | Molex/JST/Customized | ||
| Sample | Samples available | If in stock: 5–7 working days preparation; if not in stock: approximately 12 working days preparation. Stock status subject to confirmation. | ||
| Shipping Time | Small quantities / Lightweight shipments：DHL: approximately 3-5 working days | Battery Shipping Line: approximately 10–12 working days to most cities Large quantities / Heavy shipments：Battery Shipping Line : approximately 10–12 working days | Sea freight: approximately 35 working days. | ||
| Charge Temperature | 0℃ to 45℃ | ||
| Discharge Temperature | -20℃ to 60℃ | Recommended Storage Temperature |
Recommended storage temperature: Room temperature (15–35°C) Storage temperature range: -20–45°C (short-term) |
| Cycle Life / Capacity Retention |
100 cycles ≥92% 300 cycles ≥88% 500 cycles ≥80% |
||
| Certifications & Documents | MSDS/SDS available; other certifications subject to evaluation based on requirements. | ||
| Model | 123464 |
|---|---|
| Capacity | 2800 mAh |
| Nominal Voltage | 3.7 V |
| Internal Resistance | <150 mΩ |
| Typical Cell Weight | 45.0 g |
| Maximum Charge Voltage | 4.2 V |
| Cell Dimensions (T×W×L) | 12*34*64 mm (T × W × L) |
| Finished Pack Dimensions (with PCM & Wires) | 12*34*66 mm (T × W × L) Note: Final dimensions may vary depending on PCM placement, wire routing, connector type, or custom installation requirements. |
| Connector | Molex/JST/Customized |
| Sample | Samples available | If in stock: 5–7 working days preparation; if not in stock: approximately 12 working days preparation. Stock status subject to confirmation. |
| Shipping Time | Small quantities / Lightweight shipments：DHL: approximately 3-5 working days | Battery Shipping Line: approximately 10–12 working days to most cities Large quantities / Heavy shipments：Battery Shipping Line : approximately 10–12 working days | Sea freight: approximately 35 working days. |
| Charge Temperature | 0℃ to 45℃ |
| Discharge Temperature | -20℃ to 60℃ |
| Recommended Storage Temperature | Recommended storage temperature: Room temperature (15–35°C) Storage temperature range: -20–45°C (short-term) |
| Cycle Life / Capacity Retention | 100 cycles ≥92% 300 cycles ≥88% 500 cycles ≥80% |
| Certifications & Documents | MSDS/SDS available; other certifications subject to evaluation based on requirements. |
Electrical & Protection Specifications
Electrical values shown below are typical reference values for preliminary selection. Protection options are configurable; final thresholds, current capability and PCM/BMS are confirmed according to the actual cell and application requirements.
| Standard Charge Current | 0.5C (1.4A) | Standard Discharge Current | 0.5C (1.4A) |
|---|---|---|---|
| Maximum Continuous Charge Current | 1.0C (2.8A) | Maximum Continuous Discharge Current | 1.0C (2.8A) |
| Discharge Cut-off Voltage | 2.75 V | Energy | 10.36 Wh |
| Cell Configuration | 1S1P | ||
| NTC Thermistor | NO / Optional | C-rate | 1.0C |
| Self-Discharge Rate | ≤ 3%/month (at 25°C) | Short-Circuit Protection | Yes |
| Over-discharge Protection Options | Typical configurable options: 2.5V / 2.7V / 2.8V / 3.0V. Delay and release voltage depend on the selected PCM. Final settings can be matched to the application. | Overcharge Protection Options | Typical configurable options for standard 3.7V Li-ion/LiPo cells: 4.25V / 4.28V / 4.30V. Final threshold and release voltage depend on the selected PCM and cell requirements. |
| Overcurrent Protection Options | Multiple PCM/BMS options are available (e.g., 0.2A / 0.5A / 1A / 2.5A / 5A / 7A / 9A, with higher-current solutions available for suitable battery packs). OCP threshold and delay depend on the selected protection circuit. Our engineers will match the PCM/BMS to the required continuous current, peak current and application requirements. | ||
| Standard Charge Current | 0.5C (1.4A) |
|---|---|
| Standard Discharge Current | 0.5C (1.4A) |
| Maximum Continuous Charge Current | 1.0C (2.8A) |
| Maximum Continuous Discharge Current | 1.0C (2.8A) |
| Discharge Cut-off Voltage | 2.75 V |
| Energy | 10.36 Wh |
| Cell Configuration | 1S1P |
| NTC Thermistor | NO / Optional |
| C-rate | 1.0C |
| Self-Discharge Rate | ≤ 3%/month (at 25°C) |
| Short-Circuit Protection | Yes |
| Over-discharge Protection Options | Typical configurable options: 2.5V / 2.7V / 2.8V / 3.0V. Delay and release voltage depend on the selected PCM. Final settings can be matched to the application. |
| Overcharge Protection Options | Typical configurable options for standard 3.7V Li-ion/LiPo cells: 4.25V / 4.28V / 4.30V. Final threshold and release voltage depend on the selected PCM and cell requirements. |
| Overcurrent Protection Options | Multiple PCM/BMS options are available (e.g., 0.2A / 0.5A / 1A / 2.5A / 5A / 7A / 9A, with higher-current solutions available for suitable battery packs). OCP threshold and delay depend on the selected protection circuit. Our engineers will match the PCM/BMS to the required continuous current, peak current and application requirements. |
